SYD-265H-1Automatic Kinematic Viscometer

Automaticity:

Standard:ASTM D445;GB/T 265

Views: 2673

Release date: 2017-03-16

Comparison column
Hide
    loading...

                                                     SYD-265H-1 Automatic Kinematic Viscometer
Summary
The instrument is designed and made as per national standard of People’s Republic of China GB/T 265 Petroleum products-Determination of kinematic viscosity and calculation of dynamic viscosity and GB/T1632-93 Test Methods for Viscosity Number and Limiting Viscosity Number of Polymers in Dilute Solution. It is suitable to determine Kinematic viscosity, viscosity number, and limiting viscosity number of oils and polymer in dilute solution. It has been widely used in the field of pharmaceutics, petroleum, chemistry, scientific research, and metrology.

I. Main technical features
1. This instrument adopts micro-computer as the central control component,with 10.2 inch color LCD display and touch screen. It achieves prompt type operation to judge the fault,error message and trouble shooting capacity.

2.Using the new type temperature sensor and calculation way,the resolution can reach 0.001℃,accuracy is ±0.04℃.

3.Floor stand,all in one machine,Both A and B working units can test the 2 different samples in synchronization or asynchronization by automatically or hand.

4.Automatical test process includes constant temperature,oil sample updraught,detecting,calculating,viscometer cleanout,fully automatically drying,and store 100 detecting records.

5.Using one or two types cleanout fluids to wash,make sure the viscometer clean before drying,the cleanout time  can be set freedom.
6.With the viscometer calibration program [JJG155] and with the viscosity index calculator.

II. Main technical specifications
1、Temperature sensor:Pt1000
2、Temperature range: 15℃~120℃
3、Temperature resolution:0.001℃
4、Temperature control accuracy: ±0.04℃
5、Timing accuracy:±0.1s、resolution ratio 0.01s
6、Sample quantity:2 pcs
7、Usage environment:temperature 15℃~35℃、humidity less 85%
8、Power supply:AC220V ±10%  50Hz±1Hz
9、Total consumption:≤2100W
10、Outline dimension:550mm×600mm×1350mm(L×W×H)
11、Net weight: 125kg
Note:The instrument with standard configuration 4 pces Ubbelohde capillary tubes, The inner diameters for each is 0.8㎜、1.0㎜、1.2㎜ and 1.5㎜,If the user need other kinds of viscometer,pls inform us for customizing.
